Horse Barn
Designs
from North Dakota State University Agricultural Extension Service
Print free
design plans and building details for horse barns,
stables, horse shelters and pole barns.
Pole Frame Horse Shelters for Hot Climates
Two, three and four stall designs.
Post-Frame (Pole Barn) Gambrel Roof Horse
Barn This 26'x48' design has three 12'x13' stalls, a
feed room, a tack room and a big loft.
Small Gambrel Roof Horse Barn
This attractive design has two 9'x11' stalls, a tack storage
area and a loft.
Two Stall Horse Shelter This
truss-roof, pole barn has a big tack and feed room and a covered
grooming area.
Gambrel Roof Horse Stable This
pretty 24'x48' pole barn can have three or four 12'x12' stalls.
Post-Frame (Pole Barn) Stable
This 20'x60' building has an 8' wide covered grooming area in
front of up to five 12'x12' stalls. Or, use four stalls and have
a space for tack and feed.
Small Barn for Two Horses This
attractive little building has it all: two 12'-6"x12'-6" stalls,
a tach room, a feed room, a covered grooming area and an
optional loft.
More Horse Barn Designs
About These Cooperative Extension Plans: These plans
were developed over many years by engineers at U.S. Land Grant
universities. They are generally older plans that need to be
revised for today's construction methods, codes and standards.
They provide design ideas and conceptual information for
planning purposes. The plans were prepared through the USDA
Cooperative Farm Buildings Plan Exchange.
Buildings must
resist various forces from snow, wind, earthquake and use. They
also must adhere to local building and zoning codes. A local
building inspector, engineer, building supplier, or building
contractor can help you determine what is a safe and legal
building for your area.
|
